Inverter | 6SL3210-1PE22-7UL0

Inverter ｜ 6SL3210-1PE22-7UL0

Last selling price : 779 €

Product Info :

• Conditions: new
• Unit: 1 Item
• Weight: 4.7 Kg
• Hs Code: 85044095
• Volumetric weight : 2.56 Kg/m³
• Country : United Kingdom

Delivery Details :

Our Last lead time 2 week(s) . Delivery & Return

Add To Wishlist Ask a Question Share

Description
Download Datasheet

The SINAMICS PM240-2 Power Module is a compact inverter module designed for industrial applications. It operates on a 3-phase AC input voltage of 380–480V ±10% at 47–63Hz. The module delivers a high overload output of 7.5 kW (200% for 3s, 150% for 57s, 100% for 240s) at ambient temperatures up to 50°C, and a low overload output of 11 kW (150% for 3s, 110% for 57s, 100% for 240s) at ambient temperatures up to 40°C. It features an integrated braking chopper, IP20 protection, and dimensions of 355 x 140 x 165 mm (HxWxD). The module is compatible with CU firmware version V4.6 and does not include a control unit or operator panel.
