Is a compact, permanent-magnet synchronous motor designed for high-performance applications. It features a rated power of 3.3 kW, a rated torque of 16 Nm (at 100 K), and operates at a nominal speed of 3000 rpm. The motor is naturally cooled and conforms to the IMB5 mounting design (IM V1, IM V3). It includes a rotatable power connector and is equipped with a 20-bit + 12-bit multiturn absolute encoder (AM20DQI) featuring a DRIVE-CLiQ interface. The motor has a smooth shaft with tolerance N, includes a holding brake, and offers protection ratings of IP65 at the drive end flange and IP67 overall.
DATASHEET For this Product...
